AutoCAD Title Block
This pre made title block not only allows you to simply add to your AutoCAD easily but it comes with a number of features such as;Dynamic block to let you make it fit to any size of paper easilyPre made attributes to stop the timley, mundane tasks of typing in generic bits of information such as author details, drawing number etcScale has will set automatically using pre made attributes, so never worry about forgetting again!Tick boxes and stamps to display drawing purpose.All you need to do is simply add you own company logo to this template and its yours to use forever.
AutoCAD Drawing Template
This template allows you to simply add it into your AutoCAD. The template comes with paper sizes A0, A1, A2, A3 and A4. All you need to do is simply add your company logo to each paper. The template comes with a number of features that have been pre made to make your life much easier. These features include;Tick boxes and stamps to state the purpose of the drawingDynamic block so you can change the size of the block is neededViewport has been added and the scale it automatically added to the informationPre made attributes such as paper size, date, author etc to save you time typing in repetitive information.
AutoCAD Manhole Blocks
Manhole blocks can be used to drop into your drainage strategy plan to ensure that manholes will not clash with each other. They are a great way to show the differences between manhole chambers (ie foul/storm/catch pit) in your drawing and are colour coded to separate the types. The manhole block sizes available in this DWG are; 1.2m (Internal Diameter) 1.5m (Internal Diameter) 1.8m (Internal Diameter) 2.1m (Internal Diameter) 2.4m (Internal Diameter) Choose from any of the sizes above for; Foul Chambers Storm Chambers Catch Pit Chambers NB: The sizes of these chambers are in respect to the internal diameter of the chamber only. Ensure you check the wall thickness of the chambers you will be installing on site and add this to the internal dimensions to ensure your chambers will not clash on site.
